General Characteristics

Designed for terminal block and Din component applications with higher number of entries into the duct. Lead free.

• Smooth wire entry allows for quick insertion of wires
• Built-in wire retainer - double restricted slots on some sizes
• Smooth fingers will not injure the installer or damage cables
• Staggered mounting hole pattern for use in cabinets which are designed to these standards.
• Double scoreline allows easy removal of wall section or individual fingers by hand without the use of tools
• Non-slip cover with exclusive cover design with maximum grip
• RoHS Certified - Lead Free
• Manufactured in 2m lengths

Technical Characteristics

• Wire ducts with 4mm slots
• Self extinguishing rigid PVC Class 1 (UL94-VO)
• Colour: Grey - RAL7030

Certifications and compliance

• A Norme EN50085-2-3
• CSA
• UR
• RINA
• CE marked
